Teac PL-D2000 - SUBWOOFER CONTROLS

PRO LOGIC+SCART PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09141000 PROLOGIC+SCARTPCBASSY
[J,US,C,HK,SG,K,NZ]
9A09141040 PROLOGIC+SCARTPCBASSY
[E,UK,SAF,F]
9A09142000 PROLOGIC+SCARTPCB
9A09141400 PCBBKT
9A09116000 SCREW,M3X6X0.5P
CN601 9A09042600 CONNECTOR,TUC‑P15X‑B1
IC601 9A09141600 IC,LV1035M
IC602 9A09123800 IC,JRC4558D
JK101 9A09141300 JACKRCA,RED/GRN/BLU
JK103 9A09141500 RCAJACK,1PYELLOW
JK104 9A09141200 DINJACK,4PINDSW‑04DVD
L601 9A08305300 CHOKE,10UH
Q601 9A07450400 TR,2SC2001L
Q603,Q604 9A07461700 TR,2SC2878
XL601 9A08305800 RESONATOR,8MHZ
ZD601 9A08820300 DIODE,ZENER9.1‑9.5V0.5W
JACK SWITCH PCB ASSY [SUB WOOFER]
REF.NO. PARTSNO. DESCRIPTION
9A09133600 JACKSWITCHPCBASSY
9A09134000 JACKSWITCHPCB
JK301 9A09125000 RCAJACK,1PBLK
SW301 9A09133800 SW,SLIDE
LED+SW PCB ASSY (GATHER) [SUB WOOFER]
REF.NO. PARTSNO. DESCRIPTION
9A09140100 LED+SWPCBASSY
SSWWPPCCBBAASSSSYY
9A09140200 SWPCBASSY
C920£ 9A07464900 C,SAFETY0.01UF20%
SW920£ 9A09117000 SW,PUSHP12
LLEEDDPPCCBBAASSSSYY
9A09140300 LEDPCBASSY
D920 9A09140700 LED,ORG/GREEN
AMP PCB ASSY [SUB WOOFER]
REF.NO. PARTSNO. DESCRIPTION
9A09134100 AMPPCBASSY
9A09136100 AUDIOAMPPCB
9A09134500 HEATSINK
9A09028900 BRACKET
9A08755400 SCREW,M3.0XL8.0XP0.5
9A09134700 SCREW,T3.0XL12.0MMBLK
BD901£ 9A09135600 RECTIFIER,RS402L
C905,C906£ 9A08829600 C,ELECT4700UF/50V20%
CN301 9A08300000 CONNECTOR,B3B‑PH‑K
CN401 9A08309300 CONNECTOR,B2B‑XH‑A2PIN
CN501 9A09135900 WIRETERM
CN901 9A09134400 CONNECTOR,3P
D401‑D404 9A07449400 DIODE,1N4148
D501,D507 9A07461600 RECTIFIER,1N4001
D502‑D504 9A07449400 DIODE,1N4148
D506 9A07449400 DIODE,1N4148
F901,F902£ 9A09198300 FUSE,4A125VSLOW
F901,F902 9A07451800 FUSECLIP
IC401 9A08825400 IC,TL074CN
L501 9A07464000 RFCOIL,1UH
Q401‑Q404 9A07449500 TR,2SC945P
Q501,Q502 9A07449500 TR,2SC945P
Q504,Q505 9A07449500 TR,2SC945P
Q506 9A07449600 TR,2SA733Q,P
Q507,Q508 9A07449600 TR,2SA733Q,P
Q509,Q510 9A07449500 TR,2SC945P
Q511 9A07463900 TR,2SA965‑Y
Q512 9A07463600 TR,2SC2235‑Y
Q513£ 9A09135800 TR,2SA1941‑O
Q513,Q514 9A09134600 MICASHEET
Q514£ 9A09135700 TR,2SC5198‑O
Q515,Q518 9A07449600 TR,2SA733Q,P
Q516,Q517 9A07449500 TR,2SC945P
R513,R517£ 9A09135300 R,0.22OHM5W5%
R520,R522£ 9A07458200 R,4.7OHM1/2W
R521£ 9A09136300 R,3.9KOHM1/2W5%
R525£ 9A09135200 R,620OHM2W5%
R901£ 9A09135400 R,470OHM2W5%
R902£ 9A09135500 R,560OHM2W5%
RL501 9A09134900 RELAY,RPA‑12V
ZD501 9A08310000 DIODE,ZENER11.9‑12.4V0.5W
ZD502‑504 9A09137000 DIODEZENER14.5‑15.1V0.5W
−22−
