POWER PCB ASSY (GATHER)
REF.NO. PARTSNO. DESCRIPTION
9A09025800 POWERPCBASSY(GATHER)
9A08309800 POWERPCB
POWER PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09049700 POWERPCBASSY
C915,C916£ 9A07457400 C,ELECT2200UF/35V
C917,C918£ 9A08308300 C,ELECT3300UF/50V
C927£ 9A09050300 C,ELECT22UF/35V
C930£ 9A08308400 C,ELECT470UF/50V
CN202A 9A07466000 CONNECTOR,B4B‑XH‑A4PIN
CN902 9A07451700 CONNECTOR,6PINCL3962WVO
CN904 9A08308200 CONNECTOR,5PINCL3962WVO
D903‑D906£ 9A07461600 RECTIFIER,1N4001
D907‑D910£ 9A09050000 RECTIFIER,P600G
D915£ 9A07461600 RECTIFIER,1N4001
D916£ 9A07461600 RECTIFIER,1N4001
F903,F904 9A07451800 FUSECLIP
AC POWER PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09049800 ACPOWERPCBASSY
CN901 9A08308800 CONNECTOR,4PINCL3962WVO
CN903A 9A08308900 CONNECTOR,3PINCL3962WVO
F901 9A07451800 FUSECLIP
L901£ 9A09050200 ACFILTER
LP901,902 9A07465000 LPIN
−10−
