Teac PLS-85D - Main Pcb Assy

MAIN PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09025500 MAINPCBASSY
9A08303000 MAINPCB
9A07441200 HEATSINKBRACKET
9A08299400 PVCPLATE,L5.0XW5.0XT0.4M
CN201 9A08299500 CONNECTOR,B10B‑XH‑A10PIN
CN501 9A07451400 CONNECTOR,B7B‑XH‑A7PIN
CN602B 9A09027100 CONNECTOR,TUC‑P15P‑B1
CN603B 9A08299700 CONNECTOR,TUC‑P7P‑B1
CN901 9A08299600 CONNECTOR,B8B‑XH‑A8PIN
CN902 9A07451500 CONNECTOR,B5B‑XH‑A5PIN
D212‑D216 9A07449400 DIODE,1N4148
D4011 9A07449400 DIODE,1N4148
D4012 9A07449400 DIODE,1N4148
D5021 9A07449400 DIODE,1N4148
D5022 9A07449400 DIODE,1N4148
D511,D512 9A07449400 DIODE,1N4148
D521,D522 9A07449400 DIODE,1N4148
D527 9A07449400 DIODE,1N4148
D531,D532 9A07449400 DIODE,1N4148
D541,D542 9A07449400 DIODE,1N4148
D551,D552 9A07449400 DIODE,1N4148
D561,D562 9A07449400 DIODE,1N4148
D591,D592 9A07449400 DIODE,1N4148
IC201 9A09027300 IC,TC9721
IC301,302 9A05632100 IC,TC4051BP
IC303,305 9A07462800 IC,M5218AL
IC4001 9A07462800 IC,M5218AL
IC5002 9A07462800 IC,M5218AL
IC5003 9A07462800 IC,M5218AL
IC5004 9A07462800 IC,M5218AL
IC501‑506 9A07468300 IC,TDA7295
IC901£ 9A07463000 IC,MC7806ACT
IC901 9A09027400 HEATSINK(BLK)
IC901,902 9A07445500 SCREW,M3X0.5PX6MM
IC902 9A09028000 HEATSINK,H=50MM(BLK)
IC902£ 9A09027500 IC,KA7818
IC903 9A07452600 HEATSINK
IC903£ 9A07463100 IC,REGULATOR15V1A
IC904 9A09028100 HEATSINK
IC904£ 9A07463200 IC,7915
MAIN PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
J301 9A07452300 RCAJACK,RJ‑1075‑09‑0300A
J303 9A08824700 RCAJACK,4P(WHT/RED)
J305 9A07452200 RCAJACK,RJ‑1060‑09‑0300A
J502 9A09027600 SPKJACK,4PHSP‑134V‑10
J503 9A09027700 SPKJACK,8PHSP‑118V‑13
JW117 9A07449400 DIODE,1N4148
L201,L202 9A08305300 CHOKE,10UH
L511,L521 9A07464000 RFCOIL,1UH
L531,L541 9A07464000 RFCOIL,1UH
L551,L561 9A07464000 RFCOIL,1UH
P501 9A07451900 SOLDERLUG
Q201 9A07449600 TR,2SA733Q/P
Q4001 9A07449500 TR,2SC945P
Q4002 9A07449500 TR,2SC945P
Q4003 9A07449500 TR,2SC945P
Q491,Q492 9A07449500 TR,2SC945P
Q5021 9A07449500 TR,2SC945P
Q5022 9A07449500 TR,2SC945P
Q511,Q512 9A07449500 TR,2SC945P
Q521,Q522 9A07449500 TR,2SC945P
Q531,Q532 9A07449500 TR,2SC945P
Q541,Q542 9A07449500 TR,2SC945P
Q551,Q552 9A07449500 TR,2SC945P
Q561,Q562 9A07449500 TR,2SC945P
Q591,Q592 9A07449600 TR,2SA733Q/P
Q901£ 9A07463800 TR,2SB772P/Q
Q902,Q909 9A07449500 TR,2SC945P
Q906,Q910 9A07449600 TR,2SA733Q/P
Q907£ 9A07463500 TR,2SD882P
R519,R529£ 9A08301200 R,0.22OHM2W
R539,R549£ 9A08301200 R,0.22OHM2W
R559,R569£ 9A08301200 R,0.22OHM2W
R597,R598£ 9A08827000 R,1.2KOHM1/2W5%CF
R907£ 9A09027900 R,18OHM7W5%
XL201 9A08300500 CRYSTAL,4.194304MHZ
ZD201 9A08305200 DIODE,ZENER4.4‑4.6V0.5W
ZD905,906 9A07461800 DIODE,ZENER6.0‑6.3V0.5W
−8−
