Teac TTDEDS2018D - Product Description; Turntable Components Overview; Controls and Connectivity

1 – Plasc dust cover
2 – Speaker
3 – Power on/o switch & volume buon
4 – An-slip foot
5 – Adaptor - Use it when playing
45rpm records with cut out centre.
6 – Tone arm/Also switch for BT.
When the Tone arm is placed on Tone
arm holder, the turntable will change
to Bluetooth mode.
7 – Tone arm li lever
8 – On / OFF Phono play Funcon selecon.
9 – Speed selecon - Three speeds available:
33.3, 45, 78 rpm
10 – Turntable plate
11 – Ceramic cartridge with diamond needle
12 – RCA out jack
13 – DC in power jack
PRODUCT DESCRIPTION
6
7
8
9
10
11
5
1
2
3
4
13
12
