Teac UD-H01 User Manual

6
A
LLRR
D
B
C
Install the
dedicated TEAC
driver software on
the computer
before connecting
the UD-H01 unit to
the computer.
(page 10)
Audio input
(LINE IN, etc.)
Stereo amplier
or Powered speaker
Computer
XLR cable
RCA audio cable
Connect one of
these cables.
USB cable
RCA digital coaxial cable
Optical digital cable
Supplied power cord
DIGITAL OUT
(COAXIAL)
DIGITAL OUT
(OPTICAL)
Wall socket
Digital audio
output device
Digital audio
output device
After all connections are complete, connect the power cord’s plug to the AC wall socket.
<
Read the instructions of each device that you intend to use with this unit.
<
To avoid hum and noise, do not bundle the connection cords.
<
Be sure to connect each plug securely.
Connections
