Team C TM2 V2 - Rear Gear-Box; Bettery Colunm

Bettery Colunm
电池柱
Rear Gear-box
后齿轮箱
18
17
9
M3x8螺丝
M3x8 Screw
FS308/T01119
M3x8螺丝
M3x8 Screw
FS308/T01119
电池档柱
Battery Post-Short
T02181
电池柱
Battery Post
T02178
M3x12螺丝
M3x12 Screw
FS312/T08805
齿轮-16T
Gear-16T
T04041
5x8x0.2垫片
5x8x0.2 Washer
W5802/86000
5x10x4轴承
5x10x4 Ball Bearing
B051004/T02100
后齿轮箱-上盖
Rear Gear-box-Cover
T04140
后齿轮箱-底座
Rear Gear-box-Lower
T04140
M3x10螺丝
M3x10 Screw
BS310/T01115
摆臂固定座-RF
Arm Mount-RF
T04129
83中CVD
83mm Center CVD
T04044
................4
M3x8螺丝
FS308/T01119
M3x8 Screw
.........................1
M3x8螺丝
FS308/T01119
M3x8 Screw
.....................2
M3x12螺丝
FS312/T08805
M3x12 Screw
.....................2
M3x10螺丝
BS310/T01115
M3x10 Screw
5x8x0.2垫片
W5802/86000
5x8x0.2 Washer
..................................2
B051004/T02100
5x10x4轴承
5x10x4 Ball Bearing
........…………..2
