Team C TM2 V2 - Rear Suspension Arm

Rear Suspension Arm
后摆臂
27
14
=2 °
( °)
=1 °
=3 °
=3 °
=2 °
=4 °
=1 °
=0 °
=2 °
=+0 . 9 m m
( m m )
=0 m m
=- 0 . 9 m m
A N T I - S Q UA T
R F R R F F F F
R O L L - C E N T E R
=2 . 5 °
( °)
=3 . 5 °
=1 . 5 °
T O E - I N
R F R R
.............2
3x51摆臂轴
T04035 3x51 Arm PIN
.......................2
M3x12螺丝
FS312/T08805
M3x12 Screw
M3x12螺丝
M3x12 Screw
FS312/T08805
3x51摆臂轴
3x51 Arm Pin
T04035
投影调节块-1
Projection Control Block-1
T04139
摆臂固定座-RR
Arm Mount-RR
T04130
防蹲调节块-0
Squat Adjustment Block-0
T04139
