Team C TM2 V2 - Front Suspension

1
2
Front Suspension
前悬吊系统
Front Suspension
前悬吊系统
1
M3x3螺丝
M3x3 Screw
TU0222OR
M3x15螺丝
M3x15 Screw
FS315/T08807
铜座
Copper Base
TU0222OR
前底盤
Front Chassis Plate
T02008
前防撞板
Front Bumper
T02185
球头-长
Ball Stud-Long
TS4042
前上摆臂座
Front Upper Suspension Arm Mount
T02015
前下摆臂座
Front Arm Mount
TU0222OR
前下摆臂
Front Lower Arm
T02016
2.3 E扣
2.3 E-ring
T02056
前摆臂固定片
Front Hinge Pin Brace
TU0226OR
3x34.5前摆臂轴-内
3x34.5 Hinge Pin Front-Inner
T02056
..............................................2
...............2
................................................4
M3x3螺丝
TU0222OR
M3x3 Screw
2.3 E扣
T02056 2.3 E-ing
3x34.5前摆臂轴-内
T02056 3x34.5 Hinge Pin Front-Inner
........4
.................2
M3x15螺丝
FS315/T08807
M3x15 Screw
球头-长
TS4042 Ball Stud-Long
F
R
