Team C TM2 V2 - Rear Hub Carrier; Rear Lower Arm

Assemble both Left and Right
组装左和右
Rear Lower Arm
后下摆臂
Rear Hub Carrier
后轮座
26
25
L
R
13
2x9.8钢针
2x9.8 Pin
P210/T04032
M2x5螺丝
M2x5 Screw
T02244
六角座-14mm
Hex Mount-14mm
T02244
5x10x4轴承
5x10x4 Ball Bearing
B051004/T02100
5x13x4轴承
5x13x4 Ball Bearing
B051304
后轮座
Rear Hub
T04134
.............................2
2x9.8钢针
P210/T04032 2x9.8 Pin
...........…………...2
M2x5螺丝
T02244
M2x5 Screw
........…………...2
5x13x4轴承
B051304
5x13x4 Ball Bearing
........………..2
< L >
< R >
62mm前CVD
62mm Front CVD
T04156
3x32摆臂轴
3x32Arm PIN
T04105
后下摆臂
Rear Lower Arm
T04112
轴距垫片
Wheelbase Washer
T04112
M3x3螺丝
M3x3 Screw
SS303/T01122
M3x8螺丝
M3x8 Screw
SS308/T01095
.......................2
M3x8螺丝
SS308/T01095
M3x8 Screw
................................2
............................4
M3x3螺丝
SS303/T01122
M3x3 Screw
轴距垫片
T04112 Wheelbase Washer
B051004/T02100
5x10x4轴承
5x10x4 Ball Bearing
