Team C TM2 V2 - Wheel

21
41
Wheel
轮胎
42
Wheel
轮胎
X
X
X
X
x2
< Front >
< Rear >
x2
After fitting wheels to tyres,
轮胎裝好后如图打胶水
apply instant glue as shown
F
R
x2
Glue
膠水
Glue
膠水
前轮框-12mm
Front Rim-12mm
T02032
后轮框-14mm
Rear Wheel-14mm
TU0444W
M4带边尼龙螺母
M4 Flanged Nylon Nut
T02084
..........................4
M4带边尼龙螺母
T02084 M4 Flanged Nylon Nut
