Pin #5.
"Stop signal control". Used if there is no information in CAN bus
about brake pedal state (check Integrator). Input #5 connect to the
end switch of the brake pedal.
Pin #6, 14.
Data bus CAN-L, CAN-H. Connects to the CAN bus of the
vehicle (check Integrator).
Pin #7.
"Engine lock". Connects to the relay that is used to prevent the
engine from launching.
Pin #8.
"Ground". Connects to the vehicles body in the area determined
by vehicle manufacturer for OEM connection.
Pin #11.
"Turn signals alternate control". Used to
control hazard lights in vehicles where CAN bus is not avaliable. For list
of vehicles that require this connection please refer to Integrato
Pin #13.
"Hood state control". Used if CANBus contains no information
about hood state.
Pin #15.
"Siren control / Horn control". Required algorithm
is set when installing the Alarm .
Pin #16.
"Power". It is connected through 3A fuse to
any non-switched +12V circuit.
CAN bus parameters indication
Geature shown following parameters:
• Hood, trunk, doors (each door individually)
• Ignition switch state (key presence, АСС, IGN, Start)
• Engine is running
• Gearbox state (for automatic – P, R, N, D; for manual – R)
• Parking brake
• Stop-signal
• Security
• Factory security system alert
• Central lock state
• Sensors ignore
• Engine RPM
• Engine temperature
Feature allow quickly check vehicle state and adjust connection
if required. Buit-ib LED is used for indication (check "Connection
scheme"). LED lights up if any parameter is selected and stays for 5
seconds or until other parameter is chosen.
"Engine RPM" and "Engine temperature" will be indicated if no
other parameters are chosen:
"Engine RPM"
— LED flashes with frequency proportional to the RPM:
1 flash per second equals 500 RPM of the engine.
"Engine temperature"
— LED flashes 1 time every time new data
received (with ignition or or the engine running).
