TEC SL-9000-ESB-X SERIES - Level Adjustment

8-1
8. LEVEL ADJUSTMENT
8. LEVEL ADJUSTMENT
8. LEVEL ADJUSTMENT
1. Level Gauge
Set the scale on a stable and level surface. Level the scale by turning the adjustable legs so that the
air bubble is inside the center circle.
When the air bubble moves toward rear, turn the front adjustable legs clockwise.
Correct
Incorrect
2. Adjustment Procedure
When the air bubble moves toward the left side, turn the right adjustable legs clockwise.
