EO18-13004
TABLE OF CONTENTS
Page
1. UNPACKING --------------------------------------------------------------------------------------------- 1- 1
1.1 Procedure---------------------------------------------------------------------------------------------------1- 1
1.2 Checks ------------------------------------------------------------------------------------------------------1- 1
1.3 Power Cord-------------------------------------------------------------------------------------------------1- 2
2. INSTALLATION PROCEDURE --------------------------------------------------------------------- 2- 1
2.1 Connecting the TRST-56 to the POS Terminal----------------------------------------------------2- 1
2.2 Connecting the Drawer ----------------------------------------------------------------------------------2- 3
2.3 Separating the Power Supply Unit (AC Adapter)--------------------------------------------------2- 4
3. DISASSEMBLY AND REASSEMBLY------------------------------------------------------------- 3- 1
3.1 Maintenance Tools ---------------------------------------------------------------------------------------3- 1
3.2 Disassembling the Main Body -------------------------------------------------------------------------3- 2
3.2.1 Removing the Power Case SA---------------------------------------------------------------3- 2
3.2.2 Removing the Printer Cover SA--------------------------------------------------------------3- 2
3.2.3 Removing the Top Cover SA -----------------------------------------------------------------3- 3
3.2.4 Removing the Mechanism Unit---------------------------------------------------------------3- 3
3.2.5 Removing the IF PCB Ass’y and Control PCB Ass’y -----------------------------------3- 4
3.2.6 Removing the AC Adapter --------------------------------------------------------------------3- 4
3.2.7 Removing the Operation Panel SA and Front Cover -----------------------------------3- 5
3.2.8 Removing the Operation PCB Ass’y--------------------------------------------------------3- 5
3.3 Disassembling the Mechanism Unit ------------------------------------------------------------------3- 6
3.3.1 Removing the Top Chassis SA --------------------------------------------------------------3- 6
3.3.2 Removing the Platen SA-----------------------------------------------------------------------3- 6
3.3.3 Removing the Center Frame SA-------------------------------------------------------------3- 7
3.3.4 Removing the Gears----------------------------------------------------------------------------3- 8
3.3.5 Removing the Auto Cutter SA----------------------------------------------------------------3- 9
3.3.6 Removing the Lock Levers--------------------------------------------------------------------3- 9
3.3.7 Removing the Pressure Arms ---------------------------------------------------------------3-10
3.3.8 Removing the Stepping Motor and Brake ------------------------------------------------3-10
3.3.9 Removing the Top Chassis SA -------------------------------------------------------------3-11
3.4 Reassembling Procedure ------------------------------------------------------------------------------3-12
3.5 Lubrication-------------------------------------------------------------------------------------------------3-12
3.5.1 Lubricant------------------------------------------------------------------------------------------3-12
3.5.2 Where to Lubricate-----------------------------------------------------------------------------3-12
