37
11. Technical Specifications
11.1 Monitor
Display size: 7” (17.8cm); Touch screen, 1024x600 pixel
Network Interface: 2.4GHz WiFi
Radiated output power max. 100mW
WiFi: IEEE802.11b/g/n (30m)
Video bit rate: 256kbps – 3.0Mbps
Protocol: TCP/IP, UDP, P2P, DNS, DHCP, RTSP, ONVIF
Connections: USB, MicroSD card slot, DC power input
Supports MicroSD(HC/XC) cards up to 128GB (FAT32/ exFAT) class10
Built-in microphone & speaker
Values for one connected camera:
File size (night; B/W): 1MB/min (32GB at least 10 days recording)
File size (day; colour): 4.5MB/min (32GB at least 5.0 days recording)
H.264/H.265 video compression
G711A-Law 16bits 8kbps audio compression
Streaming self-adaptive audio compression code
Automatic overlay loop recording
Alarm function (push message) on your Smartphone
Rechargeable replaceable battery: 2x type 18650 Li-Ion 2600mAh
Power supply: DC 5V / 2.5A
Power consumption 8W maximum
Operating conditions: 0°C~+40°C, humidity 80% or less (non-condensing)
Weight / Dimension: 500g / (L) 19.1 x (W) 12.3 x (H) 3.2cm
Colour sensor: 1/ 2.9" CMOS (2 MP)
Minimum illumination: 0.1 Lux @ (F2.0, AGC ON), 0 Lux with 3x IR LED
Viewing angle: 90° horizontal, 55° vertical
Lens / Shutter: f=3.6mm / 1/25s ~1/25000s
Day / Night mode: built-in IR-CUT filter automatic switching
Built-in microphone & speaker
Video resolution: HD (1920*1080) Smooth (640*480), max. 15fps
Motion detection ~8m (PIR 120°)
IR distance ~15m; 850nm (open space)
Connections: Power, RJ-45 (LAN)
Network Interface: 2.4GHz WiFi
Radiated output power max. 100mW
