Technibel iSeries - Component Description

10 Component description
Compressor
type HERMETIC, SINGLE ROTARY, DC INVERTER
model 5RS102XBE01
oil RB68A or Freol Alpha 68M
refrigerant R410A
motor BRUSHLESS MOTOR
n. of poles 6
rated output 700 W
winding resistance
(@20 °C)
U-V: 0,858 Ω V-W: 0,858 Ω U-W: 0,858 Ω
overload protector CS-7L 115 (WAKO ELECTRIC OR EQUIVALENCE)
Fan Motor
model ZW465B58 ( ) – ZW465B57 ( )
motor BRUSHLESS MOTOR
n. of poles 8
rated output 20 W
rpm variable, 200 ÷ 850
winding resistance
(@25 °C)
BRN (W) - BLK (U) :
206 Ω
WHT (V) - BLK (U) :
206 Ω
BRN (W) - WHT (V) :
206 Ω
4-way Valve
model SHF-4H-23U (valve) - SHF-4-10L3 (coil)
coil rating AC 220-240V 50/60Hz
coil resistance 1440 Ω ± 7% at 20°C
Electronic Expansion Valve
model CAM-BD15EX-1 (valve) - ZCAM-MD12EX-9M-B (coil)
coil rating DC 12V
coil resistance 46 Ω ± 4% at 20°C
Crankcase Heater
power 30 W
resistance 1760 Ω ± 10% at 20°C
Drip Tray Heater
power 75 W
resistance 700 Ω ± 10% at 20°C
GR9FI30LTR5IAA
GR9FI40LTR5IAA
MOD.30
MOD.40
