Audio Input Connections
LINE RCA (Red and White) & 1/8” Inputs
Connecting a Signal Source (DVD / MIXER / MP3)
The speaker has RCA & 1/8” (AUX) input jacks on the rear of the unit which is designed to receive the signal
directly from your CD, mixer, MP3 player or any of your other audio sources. To ensure that you have correctly
connected your CD player (other sound sources) to the unit, make sure that the CD player has a cable coming from
its output and that this cable is plugged into the RCA / 1/8” Input on the rear of the speaker.
The Input selector (18) should be set to the AUX / LINE IN when using the RCA or 1/8” inputs.
When the Line Input selector is set to AUX / LINE IN the LCD Screen will NOT light up. This is normal.
Only the power indicator will light up.
NOTE: BE SURE NOT TO CONNECT AN AMPLIFIER OR ANY AMPLIFIER SIGNAL INTO THE RCA INPUT
JACK. AS THIS COULD DAMAGE THE SPEAKER. NO OTHER AMPLIFIER IS NEEDED TO POWER YOUR
SIGNAL IN ADDITION TO THE SPEAKER. ALWAYS MAKE SURE THAT THERE IS ONLY ONE AMPLIFIER IN
THE SIGNAL PATH.
Set the Input selector button to Aux / Line IN
When using the 1/8” or RCA LINE IN.
Picture above shows 1/8” cable connecting to
the AUX IN
Picture above shows a RCA cable connecting
to the LINE IN (TOP).
