10
1
GETTING
ST
ARTED
DMS3-CTC-25-114 v1.0
Cable port (item D)
The Cable port allows you to connect to the broadband network of your services provider.
Power inlet (item E)
The power inlet (Power) allows you to connect the power cord.
Bottom LED
(Amber)
Solid on Connected to a 100Mbps/10Mbps device.
Blinking Connected to a 100Mbps/10Mbps device and sending/receiving data.
Off Not connected to a 100Mbps/10Mbps device.
LED LED status Description
