9
RQT5818
Connections
Connecting the AC mains lead and other information
c To household
mains socket
a Cooling fan
The cooling fan operates at
high power output levels only.
b AC mains lead
(included)
AC mains lead
Connect this lead only after all other cables
and cords are connected.
The included AC mains lead is for use with
this unit only. Do not use it with other
equipment.
Insertion of Connector
Even when the connector is perfectly inserted,
depending on the type of inlet used, the front
part of the connector may jut out as shown in
the drawing.
However there is no problem using the unit.
Note
f Appliance inlet
e Approx. 6 mm
d Connector
(FOR THE UNITED KINGDOM ONLY)
READ THE CAUTION FOR THE
AC MAINS LEAD ON PAGE 4
BEFORE CONNECTION.
To Next Page
