<IA>: English
<IB>: Arabic, Spanish
- The parenthesized indications in the Remarks columns specify the areas. (Refer
to the cover page for area.)
- The marking [RTL] indicates that Retention Time is Limited for this item. After the
discontinuation of this assembly in production, the item will continue to be
available for a specific period of time. The retention period of availability is
dependenton the type of assembly, and in accordance with the laws governing
part and product retention. After the end of this period, the assembly will no
longer be available.
- All parts are supplied by MESA.
Ref. No. Part No. Part Name & Description Pcs Remarks
1 RKM0395F-S TOP CABINET 1 (GN)
1 RKM0395G-S TOP CABINET 1 (GC)
2 RHD30007-1S SCREW 4
3 XTBS3+10JFZ1 SCREW 1
4 REX0967 WIRE ASS'Y 1
5 RMQ1018 GASKET 1
6 RGW0317-S KNOB,VOLUME 1
7 RHN90001 NUT 1
8 RKA0106-N FOOT RING 4
9 RKF0606L-K1 BACK GRILL 1
10 RKW0581-1V FL WINDOW 1
11 RMN0427A CABLE HOLDER 1
12 RYP1005A-S FRONT PANEL ASS'Y 1
12-1 RGB0025-A TECHNICS BADGE 1
13 SHG1654 RUBBER 4
14 XTB3+10JFZ SCREW 11
15 XTB3+8JFZ SCREW 12
16 XTW3+15T SCREW 2
17 XTBS3+8JFZ1 SCREW 2
18 RGW0178-1S KNOB,MIC VOL. 1
19 RMN0582 HOLDER 1
20 XTB3+12FFZ SCREW 1
21 XTB3+20JFZ SCREW 1
22 REM0057 FAN UNIT 1 L6FAKKDG0001
(GC)
23 RGN2021-K NAME PLATE 1 (GC)
23 RGN2020-K NAME PLATE 1 (GN)
A1 EUR7702060 REMOTE CONTROL UNIT 1
A1-1 UR64EC2337E BATT.COVER 1
A2 REE0853 SP CORD(GRAY/BLUE) 2
A3 REE1057 SP CORD(RED/BLACK) 2
35
