Notes:
- Important safety notice:
Components identified by mark have special characteristics important for
safety.
Furthermore, special parts which have purposes of fire-retardant (resistors),
high-quality sound (capacitors), low-noise (resistors), etc. are used.
When replacing any of components, be sure to use only manufactures
specified parts shown in the parts list.
- The marking [RTL] indicates that Retention Time is Limited for this item. After
the discontinuation of this assembly in production, the item will continue to
be available for a specific period of time. The retention period of availability is
dependenton the type of assembly, and in accordance with the laws
governing part and product retention. After the end of this period, the
assembly will no longer be available.
- All parts are supplied by MESA.
Ref. No. Part No. Part Name & Description Pcs Remarks
1 RHD30082-K SCREW 4
2 RKM0413A-N CABINET 1
3 XTBS3+8JFZ1 SCREW 1
4 RGK1326-M SIDE PANEL(L) 1
5 RGK1327-M SIDE PANEL(R) 1
6 REZ1056-2 FFC(23P) 1
7 RGK1322-S TRAY ORNAMENT 1
8 RKA0114-K FOOT 4
8-1 RKA0083-K CUSHION 4
9 RYP0973-S SUB PANEL UNIT 1
10 RGK1330-S SIDE ORNAMENT(L) 1
11 RGL0528-Q PANEL LIGHT 1
12 RGK1331-S SIDE ORNAMENT(R) 1
13 SHE170-2 P.C.B. SUPPORT 1
14 XTBS26+8J SCREW 5
15 XTB3+5JFZ SCREW 4
16 XTBS3+8JFZ1 SCREW 6
17 XTB3+12JFZ SCREW 5
18 XTB3+8JFZ SCREW 4
19 RGG0188-S FRONT PANEL 1
20 REX1080Y WIRE ASS'Y(6P) 1
21 RMN0625 MECHA SPACER(L) 1
22 RMN0626 MECHA SPACER(R) 1
101 RFKJXDT07-K LOADING CHASSIS ASS'Y 1
101-1 RDG0142 LOADING GEAR(2) 1
101-2 RDG0193 LOADING GEAR(1) 1
101-3 RDP0065 PULLEY GEAR 1
102 REM0019 LOADING MOTOR ASS'Y 1
104 RGQ0144-K DISC TRAY 1
