17
Specifications
≥ Specifications are subject to change without notice.
≥ Mass and dimensions are approximate.
≥ “Direct Stream Digital”, DSD and their logos are trademarks of Sony Corporation.
∫ GENERAL
Power supply AC 120 V, 60 Hz
Power consumption 73 W
Power consumption in standby mode Approx. 0.3 W
Power consumption in off mode Approx. 0.3 W
Dimensions (WkHkD) 340 mmk132 mmk325 mm (13
3
/8qk5
7
/32qk12
13
/16q)
Mass (Weight) Approx. 8.3 kg (18.3 lbs)
Operating temperature range 0 oC to r40 oC(r32 oF to r104 oF)
Operating humidity range 35 % to 80 % RH (no condensation)
∫ AMPLIFIER SECTION
FTC output power 45 W r 45 W (20 Hz to 20 kHz, T.H.D. 0.5 %, 8 ≠, 20 kHz LPF)
70 W r 70 W (20 Hz to 20 kHz, T.H.D. 0.5 %, 4 ≠, 20 kHz LPF)
Load impedance 4 ≠ to 16 ≠
Frequency response
PHONO (MM) 20 Hz to 20 kHz (RIAA DEVIATION w1 dB, 8 ≠)
LINE 20 Hz to 80 kHz (s3 dB, 8 ≠)
COAX1/2/3 20 Hz to 90 kHz (s3 dB, 8 ≠)
Input sensitivity/Input impedance
LINE 200 mV / 22 k≠
PHONO (MM) 2.5 mV / 47 k≠
∫ TERMINALS SECTION
Headphones jack Stereo, ‰6.3 mm (
1
/4q)
USB port
USB Standard USB 2.0 high-speed
USB Audio Class specification USB Audio Class 2.0, Asynchronous mode
Connector USB Standard B connector
Format support LPCM (32/44.1/48/88.2/96/176.4/192 kHz, 16/24/32 bit)
DSD (2.8224 MHz, 5.6448 MHz)
DSD control mode ASIO Native mode, DoP mode
DSD64/DSD128 playback
Channel 2ch
Analog input
Line input Pin jack
PHONO (MM) Pin jack
Digital input
Optical digital input Optical terminal
Coaxial digital input k3 Pin jack
Format support LPCM
System port
System control k2 ‰3.5 mm (
1
/8q) jack
SU-C700-SQT0489_PP_mst.book 17 ページ ２０１５年１月７日 水曜日 午前１０時３２分
