6.1 Schematic Diagram Notes
TOP PREVIOUS NEXT
● This schematic diagram may be modified at any time with the development of new
technology.
Notes:
❍ S801:
VGCA switch (
)
❍ S802:
Tape monitor switch (TAPE MONITOR)
❍ S804:
Input select switch (SELECTOR)
❍ S805:
Unit on/off switch (
/I)
❍ VR301:
Volume control VR (VOLUME)
