Technics SU-G700M2 User Manual

21
English
Using analogue audio input device
Operations
(21)
Analogue audio cable (not supplied)
CD recorder, etc.
You can connect the CD recorder, etc. with analogue
audio cable (not supplied) to output analogue audio
signals from this unit (LINE1/LINE2/PHONO).
Using analogue audio cable
1 Disconnect the AC mains lead.
2 Connect this unit and a CD recorder,
etc.
3 Connect the AC mains lead to this unit.
( 13)
4 Press [AMP
] to turn this unit on.
Note
• When a digital audio signal (COAX1/COAX2/
OPT1/OPT2/PC) is selected as input source
of this unit, analogue audio signal (LINE1) is
output.
• The choppy audio occurs in output audio signal
when switching the input source.
Do not input the audio signal from PRE
OUT/LINE OUT terminals to the analogue
audio input terminals of this unit. Doing so
may cause malfunction.

Technics SU-G700M2 Specifications

General

Output Power (8 Ohms)	70 W + 70 W
Output Power (4 Ohms)	140 W + 140 W
Analog Outputs	1 x Line
USB-B Input	Yes
Coaxial Digital Input	1
Headphone Output	Yes
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Load Impedance	4 Ω - 16 Ω
Digital Inputs	Coaxial, Optical, USB-B
Analog Inputs	2 x Line
Phono Input	Yes
DAC	Yes
Bluetooth	Yes
Dimensions (W x H x D)	430 x 148 x 428 mm
