Technics SU-G700M2

31
English
Others
(31)
■ GENERAL
Power supply
AC 220 V to 240 V,
50/60 Hz
Power
consumption
95 W
Power
consumption in
standby mode
Approx. 0.5 W
Dimensions
(W×H×D)
430 mm × 148 mm ×
428 mm
Mass Approx. 12.6 kg
Operating
temperature range
0 °C to 40 °C
Operating humidity
range
35 % to 80 % RH
(no condensation)
■ AMPLIFIER SECTION
Output power
70 W + 70 W
(1 kHz, T.H.D. 0.5 %, 8 ,
20 kHz LPF)
140 W + 140 W
(1 kHz, T.H.D. 0.5 %, 4 ,
20 kHz LPF)
Load impedance 4  - 16 
Frequency
response
PHONO
(MM/MC)
20 Hz to 20 kHz
(RIAA DEVIATION ±1 dB,
8 )
LINE
5 Hz to 80 kHz
(-3 dB, 8 )
DIGITAL
5 Hz to 90 kHz
(-3 dB, 8 )
Input sensitivity/
Input impedance
PHONO (MM) 2.5 mV / 47 k
PHONO (MC) 300 uV / 100 
LINE 200 mV / 22 k
■ TERMINALS SECTION
Headphones Jack
Stereo, 6.3 mm
0.75 mW, 32 
PC
REAR USB
Type B Connector
Analogue input
LINE IN ×2 (Pin Jack)
PHONO (MM/MC),
(Pin Jack)
Digital input
OPT IN ×2
(Optical terminal)
COAX IN ×2 (Pin Jack)
Format support LPCM
Analogue output
LINE OUT (Pin Jack)
PRE OUT (Pin Jack)
System port
System control  3.5 mm, Jack
■ FORMAT SECTION
USB-B
USB Standard
USB 2.0 high-speed
USB Audio Class 2.0,
Asynchronous mode
Format support
PCM
32, 44.1, 48, 88.2,
96, 176.4, 192, 352.8,
384 kHz/
16, 24, 32 bit
DSD 2.8, 5.6, 11.2 MHz
DSD control mode
ASIO Native mode,
DoP mode
• If you download and install the dedicated app, you can play back files in wide-ranging formats. ( 15)
For details, refer to the operating instructions of the app.
• Playback of all formats supported by this unit is not guaranteed.
• Playback of a format not supported by this unit may cause choppy audio or noise. In such cases, check to
see if this unit supports the format.
• File information (sampling frequency, etc.) shown by this unit and playback software may differ from each
other.
Note
• Specifications are subject to change without notice.
• Mass and dimensions are approximate.
• DSD is a trademark of Sony Corporation.
Specifications
