28
(28)
Others
Specifications
■ GENERAL
Power supply
AC 220 V to 240 V,
50/60 Hz
Power
consumption
220 W
Power
consumption in
standby mode
Approx. 0.3 W
Dimensions
(W×H×D)
430 mm × 191 mm ×
459 mm
Mass Approx. 22.8 kg
Operating
temperature range
0 °C to 40 °C
Operating humidity
range
35 % to 80 % RH
(no condensation)
■ AMPLIFIER SECTION
Output power
150 W + 150 W
(1 kHz, T.H.D. 0.5 %, 8 ,
20 kHz LPF)
300 W + 300 W
(1 kHz, T.H.D. 0.5 %, 4 ,
20 kHz LPF)
Load impedance 4 - 16
Frequency
response
PHONO (MM)
20 Hz to 20 kHz
(RIAA DEVIATION ±1 dB,
8 )
LINE
5 Hz to 80 kHz
(-3 dB, 8 )
DIGITAL IN
5 Hz to 80 kHz
(-3 dB, 8 )
Input sensitivity/
Input impedance
PHONO (MM) 2.5 mV / 47 k
PHONO (MC) 300 mV / 100 k
LINE 200 mV / 22 k
■ TERMINALS SECTION
Headphones Jack
Stereo, 6.3 mm
0.75 mW, 32
PC
REAR USB
Type B Connector ×2
Analogue input
LINE ×2 Pin jack
LINE XLR
BALANCED
3-pin XLR
PHONO
(MM/MC)
Pin jack
PHONO XLR
BALANCED
(MC)
3-pin XLR
MAIN IN Pin jack
REC IN Pin jack
Digital input
Optical digital
input ×2
Optical terminal
Coaxial digital
input ×2
Pin jack
Format support LPCM
Analogue output
REC OUT Pin jack
PRE OUT Pin jack
System port
System control 3.5 mm, Jack
■ FORMAT SECTION
USB-B
USB Standard
USB 2.0 High-speed
USB Audio Class 2.0,
Asynchronous mode
DSD control mode
ASIO Native mode,
DoP mode
■ Format support
This unit supports the following formats.
• Playback of all formats supported by this unit is not guaranteed.
• Playback of a format not supported by this unit may cause choppy audio or noise. In such cases, check to
see if this unit supports the format.
• File information (sampling frequency, etc.) shown by this unit and playback software may differ from each
other.
