DETACHING THE STAND & WALL MOUNTING
IMPORTANT - BEFORE DRILLING ANY HOLES IN THE WALL ENSURE YOU ARE NOT DRILLING
WHERE THERE COULD BE ANY ELECTRIC WIRES, WATER OR GAS PIPES
This television requires a VESA 200 x 400 wall mount, or equivalent.
Detaching the Stand
1) Remove the six screws indicated below
2) The stand will now come off
Wall mounting the TV
1) Remove the four screws highlighted below.
2) The wall mount can now be easily attached 3) Although there are no live parts exposed when removing
to the mounting holes on the rear of the TV. the stand, (in the event of wall mounting the TV) for These
holes are indicated in the picture below. aesthetic purposes, included in the accessory pack is a
cover plate which can be clipped into the underside of the
TV.
7
User Guide
200 x 400
Important – If wall mounting this TV,
only use the screws already
provided in the wall mounting holes.
Using other screws which are longer
could cause irreparable damage to
internal parts.
