TechniSat DIGITRADIO 10 C User Manual

133
DE
EN
FR
NL
> Press the OK buon.
> Select [Normal] for a sound quality optimally tuned to the device, or [MyEQ
...] to set the treble and bass manually. Additional preset options (Classic, Jazz,
Pop, Rock and Speaking) are also available. Press the OK buon to accept the
selection.
10.3.1 MyEQ
> Select MENU > [Sound Seings] > [Equaliser] > [MyEQ] and press OK.
> Use  /  to select either [Treble] to adjust the treble, or [Bass] to adjust the
bass. Then press OK.
> Use  /  to set a value between -7 and +7. Press the OK buon to accept
the seing.
The equaliser can also be accessed using the EQ buon (15).
11 System seings
All seings explained in this section apply equally to all sources.

TechniSat DIGITRADIO 10 C Specifications

General

Package depth	173 mm
Package width	175 mm
Package height	80 mm
Package weight	612 g
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Audio (L/R) out	1
Bluetooth profiles	A2DP, AVRCP
Docking station included	No
Apple docking compatibility	Not supported
Radio type	Personal
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	40
Bluetooth version	4.1
Display type	TFT
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Thermometer	-
Product color	Black, Silver
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, SLK, SWE, TUR
RMS rated power	- W
Power source	AC
AC input voltage	230 V
DC input voltage	5 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	60 mm
Width	120 mm
Height	90 mm
Weight	153 g
