TechniSat DIGITRADIO 10 C User Manual

140
> The display will show [Restart ...] and the device will start with the language
selection [Language]. Use  /  to select one of the available languages and
confirm by pressing the OK buon. The device then automatically performs a
complete scan in DAB mode. While scanning, the display information shows
the progress as well as the number of digital radio stations detected. Aer
completing the station scan the first DAB+ channel is played.
11.5 SW version
Under SW Version you can check which SW version is currently installed.
> Press the MENU buon and use the  /  buons to select [System Seings]
> [SW Version] and press OK.
> The current soware version is displayed.
11.6 SW update
The SW update option is used to update the device soware and is only intended for
use when servicing.

TechniSat DIGITRADIO 10 C Specifications

General

Package depth	173 mm
Package width	175 mm
Package height	80 mm
Package weight	612 g
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Audio (L/R) out	1
Bluetooth profiles	A2DP, AVRCP
Docking station included	No
Apple docking compatibility	Not supported
Radio type	Personal
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	40
Bluetooth version	4.1
Display type	TFT
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Thermometer	-
Product color	Black, Silver
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, SLK, SWE, TUR
RMS rated power	- W
Power source	AC
AC input voltage	230 V
DC input voltage	5 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	60 mm
Width	120 mm
Height	90 mm
Weight	153 g
