1 Telescopic antenna
2 Headphone connection
3 AUX input
4 DC connection
5 Network connection
6 External antenna connection (see Section 4.3.3)
1 Illustrations
1 USB connection 8 SLEEP 15 Forward
2 VOLUME/ Power 9 BACK 16 Stop
3 SCROLL&SELECT/SNOOZE 10 PRESET 17 IR receiver
4 MUTE 11 INFO 18 Eject
5 MODE 12 Back 19 Display
6 MENU 13 Play/Pause 20 Speaker
7 ALARM 14 CD compartment
