TechniSat DIGITRADIO 602 User Manual

56
7.4.7 Displays
Current source
Station name,
track, artist,
additional info,
menu, lists
Time
Status bar
with reception
strength WLAN
and DAB+/FM,
active alarm
clock, stereo/
mono, etc.
The displays shown can vary depending on the selected function/source. Take
note of the instructions on the display.
8 Menu navigation
Menu navigation primarily takes place using the MENU, /// and OK buons
on the remote control.
The menu is divided into the respective submenu for the currently selected source
and the main menu. To navigate in submenus, select the corresponding item with
the arrow keys / and select/activate with the OK buon or alternatively the 
buon to call up/activate. "*" highlights the current selection.
You can go back one step by pressing the BACK or  buon.
Closing the menu: Press the BACK or MENU buon several times or wait for
approx. 15 seconds.
8.1 Main menu
The main menu takes you to all the functions and seings for theDIGITRADIO 602.
> Press the MENU buon to access the main menu.
If you are currently in a playback source, you can use the MENU buon to
access the submenu for this source. To reach the main menu while in the
open submenu, use the  or  > Main Menu buons to select the Main
menu item and press the OK buon.
8.2 Selecting the source
> Press the MODE buon as oen as required until the desired source is shown
on the display.
Alternatively:
> Press the MENU key.

TechniSat DIGITRADIO 602 Specifications

General

Radio type	Internet
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Radio Data System (RDS)	Yes
Frequency range	25 - 18000 Hz
RMS rated power	70 W
Number of built-in speakers	2
Display type	OLED
Display diagonal	2.7 \
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Headphone outputs	1
Headphone connectivity	3.5 mm
Projection	No
Antenna type	External
Product color	Anthracite, Silver
Volume control	Rotary
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, SWE, TUR
Power source	AC
AC input voltage	230 V
DC input voltage	18 V
AC input frequency	50 Hz
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Package depth	267 mm
Package width	470 mm
Package height	263 mm
Package weight	6200 g

Weight and Dimensions

Depth	215 mm
Width	400 mm
Height	170 mm
Weight	4970 g
