TechniSat DIGITRADIO 602 User Manual

55
DE
EN
FR
NL
DE
EN
FR
NL
7.4.1 Switching on the device
> You can use the VOLUME/ Knob (2) on the device or On/Standby (1) on
the remote control to switch the device on or back to standby.
Aer switching on for the first time, you can launch the set-up wizard
(Section 18.7). Here you can set the date and time either viaDAB/FM, Internet
or have no update (manual). The device will then aempt to establish a
connection to a WLAN network. To do so, select the corresponding WLAN
network and, if required, enter the WLAN password with the remote control.
7.4.2 Switching o the device
> You can use the VOLUME/ Knob (2) on the device or On/Standby (1) on
the remote control to switch the device back to standby. The date and time
are shown in the display.
7.4.3 Operating the device with the remote control
With the infrared remote control you can operate the most important device
functions from the comfort of your armchair. When operating the device with the
remote control, please take into account the following points:
> Point the remote control at the front of the device.
> Visual contact between the transmier and the receiver must be guaranteed.
> If the range of the remote control reduces, replace the baeries.
The maximum range is approximately 5 metres from the front of the device.
7.4.4 Adjusting the volume
> Use the Volume +/- (15) buons on the remote control or VOLUME/ Knob
(2) on the device to set the volume. The set volume is shown on the display.
7.4.5 Activating the mute function
> You can switch o the volume by pressing the MUTE buon (4) on the
device or MUTE (13) on the remote control.
This mode is indicated in the status bar by a corresponding icon.
> Pressing the MUTE buon again switches the volume back on.
7.4.6 Accessing displays
> By pressing the INFO buon (11) on the device or INFO (16) on the remote
control while playing from a source, you can show and scroll through the
following information:

TechniSat DIGITRADIO 602 Specifications

General

Radio type	Internet
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Radio Data System (RDS)	Yes
Frequency range	25 - 18000 Hz
RMS rated power	70 W
Number of built-in speakers	2
Display type	OLED
Display diagonal	2.7 \
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Headphone outputs	1
Headphone connectivity	3.5 mm
Projection	No
Antenna type	External
Product color	Anthracite, Silver
Volume control	Rotary
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, SWE, TUR
Power source	AC
AC input voltage	230 V
DC input voltage	18 V
AC input frequency	50 Hz
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Package depth	267 mm
Package width	470 mm
Package height	263 mm
Package weight	6200 g

Weight and Dimensions

Depth	215 mm
Width	400 mm
Height	170 mm
Weight	4970 g
