To close the menu: Press the M buon several times (depending
on which submenu you are in) until the current radio channel is
displayed again.
Seings are not saved until the OK buon is pressed. If the M buon
is pressed instead, the seings are not accepted or saved (in this
case the M buon acts as a “Back” buon).
The functions and buons to be pressed are shown in bold in this
instruction manual. Displays in [square brackets].

TechniSat TECHNIRADIO RDR Specifications

General

Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM
Radio Data System (RDS)	Yes
Preset stations quantity	20
Projection	No
Thermometer	-
Antenna type	Internal
Product color	Grey, White
Headphone outputs	1
USB connector type	Mini-USB, USB Type-A
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	2
Display type	LCD
Apple docking compatibility	Not supported
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
RMS rated power	1 W
Power source	AC/Battery
AC input voltage	230 V
AC input frequency	50 Hz
Battery voltage	3.7 V
Battery capacity	800 mAh
Battery life (max)	10 h
Cables included	Mini-USB
Package depth	46 mm
Package width	148 mm
Package height	72 mm
Package weight	200 g

Weight and Dimensions

Depth	23 mm
Width	127 mm
Height	58 mm
Weight	124 g
