data services, which are broadcast individually by the radio stations. For
further information go to www.dabplus.de or www.dabplus.ch.
5.1.1 Data compression
With this, digital radio takes advantage of the properties of human hearing.
The human ear does not perceive sounds which are found under a specific
minimum volume. Data which are found under the so-called audibility
threshold can, therefore, be filtered out. This is possible because, in a
digital data stream, the relevant relative volume for other units is saved for
every unit of information. Moreover, in an audio signal, the quieter parts
are superimposed by louder ones at a specific limit value. All the sound
information below the threshold of hearing in a piece of music can be
filtered out of the signal to be broadcast. This leads to a reduction of data

TechniSat TECHNIRADIO RDR Specifications

General

Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM
Radio Data System (RDS)	Yes
Preset stations quantity	20
Projection	No
Thermometer	-
Antenna type	Internal
Product color	Grey, White
Headphone outputs	1
USB connector type	Mini-USB, USB Type-A
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	2
Display type	LCD
Apple docking compatibility	Not supported
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
RMS rated power	1 W
Power source	AC/Battery
AC input voltage	230 V
AC input frequency	50 Hz
Battery voltage	3.7 V
Battery capacity	800 mAh
Battery life (max)	10 h
Cables included	Mini-USB
Package depth	46 mm
Package width	148 mm
Package height	72 mm
Package weight	200 g

Weight and Dimensions

Depth	23 mm
Width	127 mm
Height	58 mm
Weight	124 g
