3.1.5 PARAMETERIZATION OF THE TIMERS AND ACCESS
PERIODS
From the master programming menu select the submenu time.
The time menu contains 2 submenus itself:
z Timers
z Access periods of the codes/keys
Commands available
+ wy to select the submenu
+ # to confirm the selection
3.1.5.1 TIMERS
The timers permit scheduling of determined functions, such as arming/disarming of
the programs and activation/deactivation of bypass. The control panel provides 4
independent timers.
SELECTION OF THE TIMER
+ wy to select the timer to be programmed
+ # to confirm the selection
For every timer the following parameters can be programmed:
z Action (e.g. arming/disarming, activation/deactivation of bypass)
z Attribute (frequency of activation of the timer)
z Programs (the timer is to act on)
z Time (activation time of the timer)
z Temporary block (skip the next activation)
Commands available
+ wy to select the parameter to be programmed
+ # to confirm the selection
ACTION
Every timer can execute one of the following actions:
z Arming of the programs
z Disarming of the programs
z Activation of bypass
z Deactivation of bypass
z Activation of the remote controls
z Deactivation of the remote controls
z Arming with system status control
Commands available
+ wy to select the action to be executed
+ # to confirm the selection
+ CL-EX to confirm programming and quit
ATTRIBUTE
Every timer can be activated with the following frequencies:
z Inactive z Every holiday z Every Wednesday
z Every day z Every Sunday z Every Thursday
z Every working day z Every Monday z Every Friday
z Every holiday eve z Every Tuesday z Every Saturday
Commands available
+ wy to select the attribute of activation
+ # to confirm the selection
+ CL-EX to confirm programming and quit
PROGRAMS
Every timer can act on the programs associated.
On the display is viewed current programming for every program:
[ ] Program not associated to the timer selected
[ # ] Program associated to the timer selected
Commands available
+ # to associate the program to the timer selected
+ * to undo the existing association
+ CL-EX to confirm and quit
TIME
Every timer can be activated at a determined hour.
Commands available
+ wy to select the parameter to be modified
+ 0...9 to program the hour of activation
+ CL-EX to confirm and quit
Menu 9
Time
Time 2
Timers
Timers 1
Timer 01
Timer 01 1
Action
Timer 01 2
Attribute
Timer 01 3
Programs
Programs 1
Program 01 [ # ]
Time
12 : 32 [hh:mm]
Timer 01 4
Time
