Technoblock AS Series - Connection to Water System; Checks, Regulations and Adjustments; Electric Controls; Starting

22
Connect the unit paying attention to the colours of the supply cable wires:
a) 230V/1/50-60Hz 3 wires Blue = Neutral
Yellow/Green = Ground
Brown = Phase
We advise to install a microswitch (not supplied) on the cold room door which will
- switch on the light in the cold room, stop the unit and
- override the temperature alarm (for about one hour after door closing)
every time the door is opened.
The necessary cable is available with the unit. Connect it keeping in mind the following:
microswitch closed = door closed.
ATTENTION
Above microswitch is not supplied with the unit. If the microdoor cable is
disconnected or damaged, the same conditions will occur as in case of open door and
connected microdoor.
“K” RANGE units (K = low temperature) are supplied with a cable for door heater connection, to be made using
a fuse suitable for the door heater used.
The unit is also equipped with a cable for cold room lamp connection (lamp voltage should be 230 V and lamp
max capacity 100 Watts).
ATTENTION
Do not connect microdoor, cold room light or door heater cables to the 230V line.
Each cable is equipped with a plate showing how it should be connected.
WARNING
Any defective electrical part should be replaced by trained personnel exclusively.
The electric connection should be effected by qualified personnel.
7.2 Connection to water system ( water condenser )
This connection is only necessary if the unit has a water-cooled condenser. It is
effected by following the indications of the tags positioned by the inlet and outlet
pipes. Connection pipes should never be smaller in diameter than those on the unit. A
minimum water pressure of 1 bar is required for correct operation of the unit.
8 Electric controls:
See electronic instruments manual
9 Checks, regulations and adjustments
Before turning the unit on, check that:
- locking screws are tight
- electrical connections have been carried out correctly.
In the event that the unit has been opened:
- no tools were left inside
- assembly is correct
- there are no gas leaks
- front cover is secured correctly
9.1 Starting
Before starting the unit act as follows:
- Connect the unit to the mains. The display is turned on and shows OFF.
- If the unit has a preheating cycle, leave it in this condition for at least 3 hours.
- If the unit has a voltage monitor, leave it in this condition for at least 7 minutes to
have the counting phase carried out
- Set the required cold room temperature.
- Press ON/OFF key for 5 seconds to switch the unit on.
