Easy Lamp: Service & maintenance manual – rev. 1.0
Page 2.6
2.5. CABLES
2.5.1. POWER SUPPLY CABLE
Power supply - Electronic board
Power supply Signal Colour Electr. board
+ +14Vdc* Red P1
- GND Black P2
* It can be lower when the battery is being charged (13Vdc)
2.5.2. BATTERY CABLE
Battery - Electronic board
Battery Signal Colour Patch Conn.
+ +12Vdc Red B1
- GND Black B2
Easy Lamp current absorption is about 300mA
2.5.3. REMOTE CONTROL SENSOR CABLE
Remote control sensor - Electronic board
Remote control
sensor
Signal Colour Electr. board
Black GND Black R1
Red +4,8Vdc (power) Red R2
Blue +4,1Vdc (pulses) Blue R3
Voltage between GND and Blue wires can be used to check if remote control properly
works. In fact it is normally 4,1Vdc, but it goes to 3,8Vdc when you keep pressed the
remote control button.
2.5.4. LED LAMPS CABLE
Led lamps - Electronic board
Lamp leds Signal (off) Signal (on)* Colour Electr. board
B- GND GND White-blue B-
B+ 0
6 Vdc**
Blue B+
L1
G- GND GND White-green G-
G+ 6Vdc 11,8 Vdc Green G+
L2
R- GND GND White-Red R-
R+ 4 Vdc 7 Vdc Red R+
L3
Led lamps voltages can be measured when the lamp is working.
*That means when the lamp is lighting the colour referred to the colour of the wire.
**Blue light flashes only during lamp programming or when battery is low.
