Easy Lamp: Service & maintenance manual – rev. 1.0
Page 3.2
3.2. TUBE ASSEMBLY
It’s made of a transparent and painted tube assembly: painted tube contains batteries while
transparent tube guarantees a correct light diffusion.
Both the transparent and the painted tube assembly tube have been modified with some
notches (highlighted in the picture below), in order to allow possible battery gas coming
out from the tube, in case of battery issues.
3.3. REMOTE CONTROL SENSOR
It’s an infrared receiver sensor fixed at the bottom of the transparent tube assembly, in order to be
easily activated by the remote control. It’s connected by a 3 wires cable to the electronic board.
