Technogym Element+ - Replacing the cable

12
Lat Machine
A
E
D
C
B
cont.
Replacing the cable
To replace the cable, proceed as follows:
- dismantle the bar;
- raise the rubber gaiter (A);
- unscrew the screws (B) and extract the cable from the attachment (C);
- back off the lock nut (D) and unscrew the adjuster (E);
- extract the cable from the adjuster side;
