Lat Machine
E
D
A
C
B
Replacing the cable
- put in the adjuster (E);
- insert the rubber gaiter (A) and the attachment (C), then tighten the screws (B);
- lower the rubber gaiter (A);
- adjust the cable tension and tighten the lock nut (D);
- remove 10 mm thickness (1/2”) from the weight stack.
WARNING
ALWAYS use cables supplied directly by Technogym.
The cables must always be replaced at the first sign of wear, even if it only affects
the outer rubber protection.
WARNING
Every month, carefully inspect the condition of the cables.
