Leg Curl
Description of the equipment
A Seat: where the user sits to perform the exercise. Its position can be adjusted using the
lever (I).
B Lever: operated by the user by means of the roller (C); before starting to exercise, or
between one set and the next, the starting position can be adjusted so as to modify the
range of motion by using the ROM device.
D ROM device: system for adjusting the Range of Motion and the starting position.
Adjustments are made by means of the ROM lever (E) after having released it by operating
the button positioned on it.
F Weight stack: the lever (B), operated by the user, moves the weights along two guides
by means of a cable. A pin (G) is used for selecting the load, to adjust the exercise effort
level. The cursor (H) is used to vary the selected workload by 2,5 kg.
L Side handgrips: the user can enhance the comfort by holding them during the exercise.
