COMPASS
The compass shows the bearing in degrees due North together with 16 cardinal
points
Press COMPASS button, the unit will enter Compass mode, Hold the unit
horizontal. Point the 12 o’clock position of the unit in the direction you want to
measure. As below graph shown, the direction you are measuring now is WSW
223°.The arrow “▲” always point to North.
When the direction of compass is point to North (degree for -12.5 to +12.5), the
direction icon outside will be shown. If no key press for 30 seconds, the unit will
auto off the compass and return to temperature mode.
Note:
1. The compass must be kept in a level position when in use. Taking a measurement
while the unit is not horizontal (in relation to the horizon) can result in large
measurement error
2. Always take bearings in the open air, because it is easily affected by disturbing
sources of magnetism.
3.
