Technomark Multi 4 - USERS MANUAL - STEP 6: Reminder of the main technical features

®
STEP 6: Reminder of the main technical features
Enter le name and eventually
comments
Start marking
Conrm entered data and
conguration
Conrm entry
Select "le" menu
Select "test" menu
Turn off the mains switch ( o )
Press "save" key
Test marking (choose from: line outline
(1), le outline (2), beginning-end
line (3), line without impact (4), le
without impact (5))
15
18
21
14
17
20
13
16
19
• Power: 250 VA
• Frequency: 50 or 60 Hz
• Controller dimensions (L x W x H): 145.67’’ x 84.65’’ x 54.72’’ (370 x 215 x 139 mm)
• Electrical supply: 90 to 240 V
• Range of working temperature: 0°C to + 45°C (32°F to 115°F)
USER’S MANUAL
