Specifications
System capabilities Fully DVB compliant
Satellite
LNB/Tuner input
Connector IEC 169-24, female
Frequency range 950MHz~2150MHz
Signal level -65dBm~-25 dBm
LNB supply DC 13/18, max 400mA
LNB switch control 22KHz
DiSEqC Ver 1.0/1.1/1.2/USALS Compatible
Demodulator Front end DVB-S/S2 QPSK, 8PSK
Symbol rate DVB-S : 1~45Msps
DVB-S2 : 10~30Msps(QPSK)
10~30Msps(8PSK)
SCPC and MCPC Capable
Spectral inversion Auto conversion
TERRESTRIAL
System capabilities
Tuner & Channel
Decoder
Input connector IEC 169-2, Female
Loop-through out IEC 169-2, Male
Frequency range 170~230 MHz, 470~862MHz
Input impedance 75 Ohms Nominal
Signal level 7/8MHz(-78dBm~-25dBm) switchable by
software
IF Bandwidth 7/8MHz(-3dB) switchable by software
Waveform OFDM
Carrier Mode 2K and 8K hierarchical/non-hierarchical
Code Rate 1/2, 2/3, 3/4, 5/6, 7/8
Guard Interval 1/4, 1/8, 1/16, 1/32
System resource Processor 32bit processor (266MHz)
DDR SDRAM 128 Mbyte x 2
FLASH 16 Mbyte
EEPROM 128 Kbit
Video decoder MPEG 2 MPEG-2, MPEG-4, H-264
Data Rate Up to 15M bits/s
Resolution 1920x1080i, 1280x720p, 720x576p/i
Video format PAL
Aspec Ratio 4:3, 16:9
MPEG Audio MPEG 1 layer 1 & 2
Type Mono, Stereo, Joint Stereo
Sampling rates 32,44.1 and 48 KHz
Serial data interface Connector 9pin D-sub male, Max 115 K bps
Remote control Code NEC-IR
Operating condition Up to 7 Meter
SATA E-SATA
Internal SATA
USB USB Supply(Front/Rear) DC 5V Max 500mA
Ethernet 10 Base-T/100Base-Tx
PCMCIA 2 slot(type I or type II)
DVB Common Interface Standard
(Viaccess, Nagravision, Conax, Cryptoworks, Irdeto)
Smart card 2 slot
ISO 7816, GSM11.11 and EMV(Payment systems) Compatibility
