Technomate TM-Twin-OE - 7 Appendix; Specifications

34
7.1. Specifications
Satellite Front-End
Input Connector
F-Type, IEC 169-24, Female x 2
Loop-through Connector
F-Type, IEC 169-24, Female
Frequency Range
950MHz to 2150MHz
RF Input Level
-25dBm to -75dBm
LNB Power & Polarization
Vertical: +13V (+14V at high voltage)
Horizontal: +18V (+19V at high voltage)
Current: Max. 500mA (Overload protection)
22KHz Tone
Frequency : 22KHz, +/- 4KHz
Amplitude: 0.7V, +/- 0.2V
DiSEqC Control
Version 1.0, 1.2, USALS compatible
Demodulation
QPSK, 8PSK
Input Symbol Rate
DVB-S : 1-45 MBaud
DVB-S2 : 5-30 MBaud (QPSK), 2-30 MBaud (8PSK)
FEC Mode
DVB-S : 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 7/8, 8/9, 9/10
DVB-S2 : 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
RF Modulator
RF-Connector
75ohm IEC169-2, Male / Female
Frequency
470MHz to 860MHz
Output Channel
CH 21~CH 69 for the Demodulator
TV Standard
PAL B/G/I/D/K Selectable by Menu Setting
Audio Output
Mono with Volume Control
Preset Channel
CH 40, Software changeable by Menu screen
7. Appendix
