© Technosoft 2007 18 IBL2403 Technical Reference
3.2. Connectors and Connection Diagrams
3.2.1. Connectors Layout
IBL2403-CAN Intelligent Servo Drive
Figure 3.2. IBL2403 drive connectors
3.2.2. Identification Labels
T E C H N O S O F T
AB1234
Drive Name
Article Number
Serial Number
Manufacturer
Figure 3.3. IBL2403-RS232 Identification Label
T E C H N O S O F T
AB1234
Drive Name
Article Number
Serial Number
Manufacturer
Figure 3.4. IBL2403-CAN (CAN execution) Identification Label
T E C H N O S O F T
AB1234
Drive Name
Article Number
Serial Number
Manufacturer
Figure 3.5. IBL2403-CAN (CANopen execution for Brushless and DC motors with incremental encoder )
Identification Label
IBL2403-RS232
P037.001.E001
IBL2403-CAN
P037.001.E002
IBL2403-CAN
P037.001.E012
