2.1 Install"and"fasten"the"horizontal"bar"with"12-"M6X20"and"Install"the"
Tube"Fixing"Plate"with"16-"M6X20"as"the"image"below.
"
"
2.2 Install"the"Fan"Fixing"Plate"and"Stee l"Legs"with"8-M6X20"bol ts."
After"fastening"them,"fasten"the"Up"Fixing"Plates"of"Main"body"and"S teel"
Legs"with"12-M6X20"bolts."Install"dry"fans"on"the"fixing"plate"with"4-
M6X15"bolts(Black"Plastic"Cover).
