INSTRUCTIONS FOR THE INSTALLATION,
USE AND MAINTENANCE OF
TECNICOMAR SYSTEM FOR SEWAGE WATER TREATMENT
MODEL: ECOmar 20 S; 32 S; 45 S; 70 S; 145 S.
S
Image for illustration purposes only
Rev.
Date
Main content revisions
00
10.02.2019
Main Unit
H
2
O
2
Dosing
System
Sea
Water
Pump
Filling
Pump
H
2
O
2
Dosing
System
ECOFLOC
Dosing
System
UV Sterilization
Unit
Sludge
Valve

Table of Contents

Questions and Answers

  • D
    diane92Aug 18, 2025
    Why does my TECNICOMAR Water Dispenser system shut down for OVERLOAD ALARM fault?
    • D
      David BowenAug 18, 2025
      The TECNICOMAR Water Dispenser system might shut down due to an overload alarm for several reasons: 1. The black switch button of the circuit switch breakers may be wrongly set. Ensure it is in the ON position, pressed inside the switch circuit breaker. 2. Circuit switch breakers keep tripping, indicating a system short circuit that needs to be resolved. 3. The power supply voltage may be incorrect. Power the plant with a voltage suitable to that indicated on the system nameplate, or replace the ECOmar S STP with one suitable for the power supply line voltage. 4. A broken control box can also cause this issue; in this case, it should be repaired or replaced.
  • B
    Brittany PonceAug 20, 2025
    Why does my TECNICOMAR ECOmar 32 S Water Dispenser system shut down for FILLING ALARM fault?
    • J
      Jamie GrayAug 20, 2025
      The system may shut down due to a filling alarm fault because of: 1. A malfunctioning Min. Level Sensor of the Treatment Tank. To resolve this, clean the level sensor and reinstall it. 2. Malfunctioning Filling Pump. Open all the valves installed along each filling pump suction / delivery piping. 3. A broken control box. If this is the case, repair or replace the main control box.
  • M
    Michael WeeksAug 23, 2025
    Why does my TECNICOMAR Water Dispenser system shut down for SEAWATER ALARM fault?
    • J
      John JamesAug 23, 2025
      The TECNICOMAR Water Dispenser system might shut down due to a seawater alarm fault for these reasons: 1. A malfunctioning Max. Level Sensor of the Treatment Tank. Clean the level sensor and re-install it. 2. A malfunctioning Seawater Pump. Open all the valves installed along seawater pump suction piping. 3. A broken control box. If this is the problem, repair or replace the main control box.
  • D
    David ScottAug 26, 2025
    What to do if TECNICOMAR ECOmar 32 S Water Dispenser has excessive noise and vibrations?
    • J
      jordan23Aug 26, 2025
      If your TECNICOMAR Water Dispenser is exhibiting excessive noise and vibrations, consider the following: 1. **System pulsation**: Check the Filling /Seawater pump correct priming and the presence of any leaks or restrictions on their suction piping, and correct it. 2. **Worn seals**: Replace pumps (filling, seawater, macerating) seals. 3. **Air presence**: Pressurize the affected circuit (filling, seawater, sludge discharge, clarified water discharge), by filling it activating the relative pump. This will help to eliminate the infiltrated air.
  • D
    Denise Mosley DDSAug 28, 2025
    Why does my TECNICOMAR Water Dispenser system shut down for HIGH PRESSURE ALARM fault?
    • R
      Ryan NortonAug 28, 2025
      The TECNICOMAR Water Dispenser system may shut down due to a high-pressure alarm fault due to: 1. Wrong settings of the black switch button of the circuit switch breakers. Set the black switch button of the circuit switch breakers, in ON position, with the switch button pressed inside the switch circuit breaker. 2. Wrong or inefficient ventilation of the treatment tank. Remove any obstructions from the air relief and vent line, ensuring they are as free as possible. 3. A broken control box. If this is the case, repair or replace the main control box.
  • G
    Gwendolyn MontgomeryAug 30, 2025
    What to do if my TECNICOMAR ECOmar 32 S treated and discharged water are dark?
    • S
      Samuel NewtonAug 30, 2025
      If the treated and discharged water from your TECNICOMAR Water Dispenser is dark, check the following: 1. **H2O Dosing System**: Set the Dosing Timer parameter and the dosing pump flow regulation to the correct values shown on the attached Test Report. 2. **Safe filter**: If necessary, empty and clean the bag cartridge or replace it. 3. **Discharge Timer parameter**: Adjust the Discharge Timer parameter setting value according to the plant on board installation condition.
  • S
    Samantha ThompsonSep 2, 2025
    What to do if TECNICOMAR ECOmar 32 S Water Dispenser unit is powered correctly but does not start?
    • J
      jessica94Sep 2, 2025
      If the TECNICOMAR Water Dispenser unit is powered correctly and set in automatic mode, with 'System Running' displayed, but it doesn't start, consider these potential issues: 1. **Collecting Tank Level Probes malfunctioning**: Ensure each supplied sensor is correctly installed and connected, referring to the attached connections diagrams. 2. **Level Probe Control Box malfunctioning**: Repair or replace each supplied level probe control box. 3. **Broken control box**: Repair or replace the main control box.
  • L
    Lisa PayneSep 4, 2025
    How to fix no or low quality visualization on the TECNICOMAR ECOmar S STP display?
    • S
      Shannon AvilaSep 4, 2025
      If there is no or low-quality visualization on the display of your TECNICOMAR ECOmar S STP, consider the following: 1. **Display contrast calibration**: Re-calibrate the display contrast by acting on the trimmer P2 installed on the rear side of the P.C.B. PRO14. 2. **Display backlight settings**: Set properly the “Display Backlight Timer” parameter. 3. **Broken control box**: Repair or replace the main control box.
  • A
    Alexander NashSep 7, 2025
    What to do if TECNICOMAR ECOmar 32 S Water Dispenser Sludge Discharge Valve (V2) does not open or close?
    • S
      Samantha LewisSep 7, 2025
      If the Sludge Discharge Valve (V2) on your TECNICOMAR Water Dispenser does not open or close, it could be due to: 1. A malfunctioning Motorized valve. Set the rotation direction of the actuator to Y2. 2. A broken control box. If this is the cause, repair or replace the main control box.
  • S
    Summer WeberSep 10, 2025
    What to do if TECNICOMAR ECOmar 32 S Discharge Valve (V1) does not open or close?
    • K
      Kimberly StrongSep 10, 2025
      If the Discharge Valve (V1) on your TECNICOMAR Water Dispenser does not open or close, consider: 1. A malfunctioning Motorized valve. Set the rotation direction of the actuator to Y2. 2. A broken control box. If this is the cause, repair or replace the main control box.

Summary

System Description and Capacity

Functional Layout and Components

Details the system's main parts, installation schemes, and functional overview.

Control Panel and Operation Modes

PCB Control Panel Interface

Overview of the main screen, operation modes, and parameter settings.

Automatic vs. Manual Operation

Guide to operating the system in automatic or manual control modes.

System Alarms and Faults

Alarm Identification and Management

Details common system alarms and procedures for identification and reset.

Core Safety Instructions

Important Safety Information

General safety guidelines, user responsibilities, and operational precautions.

Instructions and Warnings

Operator warnings and precautions regarding system modifications and safety.

Safety Guidelines and Prevention

General Safety Principles

Essential safety rules and preventative measures for system use.

Pre-Operation Checks

Crucial checks to perform before turning on the system for safe operation.

Danger Information and Labels

Installation Procedures

Owner Supplied Components

Lists essential plumbing and electrical parts the owner must provide for installation.

Installation Crew Qualifications

Specifies the required technical knowledge and skills for installation personnel.

Electrical Connections Overview

Main Control Box Wiring

Instructions for connecting power and system components to the main control box.

First Start-Up Procedure

Step-by-Step Start-up Guide

Detailed instructions for the initial start-up and verification of the ECOmar S STP.

Common Problems and Troubleshooting

Troubleshooting Table Guide

A table listing common symptoms, causes, checks, and remedies for system issues.

Maintenance Instructions

Ordinary Maintenance Tasks

Routine maintenance for dosing systems, filters, and UV sterilizer.

H2 O2 Dosing System Maintenance

ECOFLOC Dosing System Maintenance

Extraordinary Maintenance

Pump and Probe Maintenance

ECOmar S Maintenance Plan
