INSTRUCTIONS FOR THE INSTALLATION,
USE AND MAINTENANCE OF
TECNICOMAR SYSTEM FOR SEWAGE WATER TREATMENT
MODEL: ECOmar 20 S; 32 S; 45 S; 70 S; 145 S.
S
Image for illustration purposes only
Rev.
Date
Main content revisions
00
10.02.2019
Main Unit
H
2
O
2
Dosing
System
Sea
Water
Pump
Filling
Pump
H
2
O
2
Dosing
System
ECOFLOC
Dosing
System
UV Sterilization
Unit
Sludge
Valve

Table of Contents

Questions and Answers

  • E
    Eric RiceAug 18, 2025
    Why does my TECNICOMAR Water Dispenser system shut down for OVERLOAD ALARM fault?
    • Y
      Yesenia HartmanAug 18, 2025
      The TECNICOMAR Water Dispenser system might shut down due to an overload alarm for several reasons: 1. The black switch button of the circuit switch breakers may be wrongly set. Ensure it is in the ON position, pressed inside the switch circuit breaker. 2. Circuit switch breakers keep tripping, indicating a system short circuit that needs to be resolved. 3. The power supply voltage may be incorrect. Power the plant with a voltage suitable to that indicated on the system nameplate, or replace the ECOmar S STP with one suitable for the power supply line voltage. 4. A broken control box can also cause this issue; in this case, it should be repaired or replaced.
  • T
    Tyler McclainAug 20, 2025
    Why does my TECNICOMAR ECOmar 45 S Water Dispenser system shut down for FILLING ALARM fault?
    • D
      David WalkerAug 20, 2025
      The system may shut down due to a filling alarm fault because of: 1. A malfunctioning Min. Level Sensor of the Treatment Tank. To resolve this, clean the level sensor and reinstall it. 2. Malfunctioning Filling Pump. Open all the valves installed along each filling pump suction / delivery piping. 3. A broken control box. If this is the case, repair or replace the main control box.
  • J
    Jesse WhitakerAug 22, 2025
    Why does my TECNICOMAR ECOmar 45 S system shut down for SEAWATER ALARM fault?
    • B
      Brandon LambAug 23, 2025
      The TECNICOMAR Water Dispenser system might shut down due to a seawater alarm fault for these reasons: 1. A malfunctioning Max. Level Sensor of the Treatment Tank. Clean the level sensor and re-install it. 2. A malfunctioning Seawater Pump. Open all the valves installed along seawater pump suction piping. 3. A broken control box. If this is the problem, repair or replace the main control box.
  • K
    kathy85Aug 26, 2025
    What to do if TECNICOMAR ECOmar 45 S has excessive noise and vibrations?
    • P
      ppierceAug 26, 2025
      If your TECNICOMAR Water Dispenser is exhibiting excessive noise and vibrations, consider the following: 1. **System pulsation**: Check the Filling /Seawater pump correct priming and the presence of any leaks or restrictions on their suction piping, and correct it. 2. **Worn seals**: Replace pumps (filling, seawater, macerating) seals. 3. **Air presence**: Pressurize the affected circuit (filling, seawater, sludge discharge, clarified water discharge), by filling it activating the relative pump. This will help to eliminate the infiltrated air.
  • S
    Stephen SmithAug 27, 2025
    Why does my TECNICOMAR Water Dispenser system shut down for HIGH PRESSURE ALARM fault?
    • D
      dsalazarAug 27, 2025
      The TECNICOMAR Water Dispenser system may shut down due to a high-pressure alarm fault due to: 1. Wrong settings of the black switch button of the circuit switch breakers. Set the black switch button of the circuit switch breakers, in ON position, with the switch button pressed inside the switch circuit breaker. 2. Wrong or inefficient ventilation of the treatment tank. Remove any obstructions from the air relief and vent line, ensuring they are as free as possible. 3. A broken control box. If this is the case, repair or replace the main control box.
  • C
    christinematthewsAug 30, 2025
    What to do if my TECNICOMAR Water Dispenser treated and discharged water are dark?
    • H
      Heather ThompsonAug 30, 2025
      If the treated and discharged water from your TECNICOMAR Water Dispenser is dark, check the following: 1. **H2O Dosing System**: Set the Dosing Timer parameter and the dosing pump flow regulation to the correct values shown on the attached Test Report. 2. **Safe filter**: If necessary, empty and clean the bag cartridge or replace it. 3. **Discharge Timer parameter**: Adjust the Discharge Timer parameter setting value according to the plant on board installation condition.
  • G
    George HarrisSep 1, 2025
    What to do if TECNICOMAR ECOmar 45 S Water Dispenser unit is powered correctly but does not start?
    • B
      Brendan StevensSep 1, 2025
      If the TECNICOMAR Water Dispenser unit is powered correctly and set in automatic mode, with 'System Running' displayed, but it doesn't start, consider these potential issues: 1. **Collecting Tank Level Probes malfunctioning**: Ensure each supplied sensor is correctly installed and connected, referring to the attached connections diagrams. 2. **Level Probe Control Box malfunctioning**: Repair or replace each supplied level probe control box. 3. **Broken control box**: Repair or replace the main control box.
  • C
    carolreidSep 4, 2025
    How to fix no or low quality visualization on the TECNICOMAR ECOmar S STP display?
    • Y
      Yvonne AlexanderSep 4, 2025
      If there is no or low-quality visualization on the display of your TECNICOMAR ECOmar S STP, consider the following: 1. **Display contrast calibration**: Re-calibrate the display contrast by acting on the trimmer P2 installed on the rear side of the P.C.B. PRO14. 2. **Display backlight settings**: Set properly the “Display Backlight Timer” parameter. 3. **Broken control box**: Repair or replace the main control box.
  • J
    Jeremy MorganSep 6, 2025
    What to do if TECNICOMAR ECOmar 45 S Sludge Discharge Valve (V2) does not open or close?
    • C
      Christine PhamSep 7, 2025
      If the Sludge Discharge Valve (V2) on your TECNICOMAR Water Dispenser does not open or close, it could be due to: 1. A malfunctioning Motorized valve. Set the rotation direction of the actuator to Y2. 2. A broken control box. If this is the cause, repair or replace the main control box.
  • J
    Jamie BushSep 9, 2025
    What to do if TECNICOMAR ECOmar 45 S Water Dispenser Discharge Valve (V1) does not open or close?
    • J
      Jennifer GriffinSep 9, 2025
      If the Discharge Valve (V1) on your TECNICOMAR Water Dispenser does not open or close, consider: 1. A malfunctioning Motorized valve. Set the rotation direction of the actuator to Y2. 2. A broken control box. If this is the cause, repair or replace the main control box.

Summary

Safety Instructions and Precautions

Important Safety Information

Crucial safety guidelines for system use, maintenance, and repair.

CE Declaration of Compliance

Danger Informations and Prevention

Information on safety labels, danger warnings, and fire prevention.

Installation Procedures

Main Unit Plumbing Connections

Loose Parts Installation

Pump and System Component Installation

Instructions for installing pumps, dosing systems, filter, and sterilizer.

Electrical Connections

Guidelines for making electrical connections to the main control box and other components.

Control Panel, Operation, and Alarms

PCB Control Panel and Modes

Alarms Description

Detailed explanation of system alarms and their corresponding causes.

Remote Control Options

Procedures, Troubleshooting, and Maintenance

Start-up, Operation, and Special Procedures

Troubleshooting Common Problems

A guide to identifying and resolving common problems and symptoms.

Maintenance Instructions

Guidance on ordinary, extraordinary maintenance, and system settings.

Technical Specifications

TECNICOMAR ECOmar 45 S Specifications

General IconGeneral
CategoryWater Dispenser
ModelECOmar 45 S
BrandTECNICOMAR
Capacity45 l/h
Frequency50 Hz
