15.5 ECOmar 145 S – Data Sheet
Main data
 Model name: ..................................................................................................................................... ECOmar 145 S
 Capacity: .................................................................................................................................................. 14500 l/day
 Duration of each cycle: .............................................................................. about 22 min. – approx. 3 cycles per hour
 Acoustic pressure level at 1 meter (Leq): ...................................................................................................... 72 dB(A)
 Treatment tank material: ................................................................................................................................... A316L
 Paint: ........................................................................................................................................................... RAL 9016
Power supply and installed power
 Main Power supply (to be confirmed in case of purchase order): 230V-50Hz-1Ph, 400V-50Hz-3Ph, 415V-50Hz-3Ph,
440V-60Hz-3Ph, 460V-50Hz-3Ph, 690V-50Hz-3Ph, 690V-60Hz-3Ph, other voltages available on request.
 Power consumption (max): ................................................................................................................................ 1,6 kW
 Heat dissipation (max): .................................................................................................................................... 0,44 kW
 Filling pump*: ..................................................................................................................... 1,1 kW-1Ph / 1,5 kW-3Ph
 Macerator/discharge pump*: ............................................................................................... 1,1 kW-1Ph / 1,5 kW-3Ph
 Sea water pump*: ............................................................................................................................................ 0,55 kW
 Dosing pumps*: ..................................................................................................................................... 2 x 0,037 Watt
 UV Sterilizer*: ............................................................................................................................................ 2 x 80 Watt
 Auxiliary power supply*: ............................................................................................................................... 24 VAC
Equipment details
 Sterilizing chemical product: ............................................................................................... Hydrogen peroxide (35%)
 Flocculant chemical product: ...................................................................................................................... ECOFLOC
 Dosing pump model: .......................................................................................................................... 5 litres/h at 7 Bar
 Dosing system tank (Hydrogen peroxide): ....................................................................................................... 30 litres
 Dosing system tank (ECOFLOC): .................................................................................................................... 20 litres
 Power supply of dosing pump*: ................................................................................................................... 230 VAC
 Three-way sludge valve (V2) size: ............................................................................................................. 1-1/4” FFF
 Pressure switch (0.1 – 1) setting (only on PP treatment tank configuration): ........................................... not available
 Filtration station – 1
st
filter FBR vessel model / quantity: ........................................................................... 10 x 35 / 1
 Filtration station – 1
st
filter Zeolite quantity: ....................................................................................................... 20 kg
 Filtration station – 1
st
filter Course quartzite quantity: ..................................................................................... 12,5 kg
 Filtration station – 2
nd
filter FBR vessel model / quantity: .......................................................................... 10 x 35 / 1
 Filtration station – 2
nd
filter Fine quartzite quantity: ........................................................................................ 31,5 kg
 Filtration station – 2
nd
filter Course quartzite quantity: .................................................................................... 12,5 kg
 Bag filter - model / quantity: ......................................................................................................................... BB-20 / 1
 Bag filter – housing model / quantity: .............................................................................................. PBH-420 (1”) / 1
 Bag filter – cartridge model / quantity: .................................................................................................... BP-420-5 / 1
 UV Sterilizer – model: ..................................................................................................................................... TC 8000
 UV Lamp – model / quantity: ..................................................................................................................... 80 Watt / 2
*Power supply derived from Main control box.
