TECNOMAGNETE QX Series - 5 General Description of the System

59
Instruction and maintenance manual
ENGLISH
5
GENERAL DESCRIPTION
OF THE SYSTEM
5.1 Systems for milling operations
The system described in the manual comprises:
• One or two magnetic chucks
• Accessories (xed and mobile polar extensions).
5.1.1 Accessories for milling
In order to be able to machine parts with small di-
mensions or discontinuous supporting surfaces,
it is possible to separately purchase the following
accessories, which include xed and mobile exten-
sions with stop:
• Fixed extension
• Mobile extension
• Double xed extension
• Fixed extension with stop
• Round mobile extension
TECNOMAGNETE S.p.A. is also able to supply on
request special and custom accessories.
5.2 Systems for grinding operations
The system described in the manual comprises:
• One or more magnetic chucks.
5.2.1 Accessories for grinding
To able to machine parts with shaped supporting
surfaces, it is possible to separately purchase sha-
peable over-plates that reproduce the polar pitch of
the chuck on which they are tted.
TECNOMAGNETE S.p.A. can however be contacted
at any time for specic requests or assistance.
Fixed extension Mobile extension
Double xed
extension
Fixed extension
with stop
Round mobile
extension
